Custom Gas Station Pylon Sign – Technical Specification

Our custom gas station signs are manufactured with durable steel or aluminum structures, weather-resistant sign panels, and energy-efficient LED lighting systems. Each pylon sign is engineered for excellent visibility, structural stability, and reliable outdoor performance. Branding graphics, fuel types, service information, and illuminated fuel price displays can all be customized to meet the requirements of different gas station projects.

Suitable for both new construction and station renovation, our pylon signage solutions are supplied with the necessary internal framework, illuminated cabinets, mounting components, LED modules, power supplies, and optional digital price control systems.

1. Materials & Components

Main Structure:
Galvanized steel or aluminum framework with anti-corrosion treatment for long-term outdoor use

Sign Panels:
Aluminum composite panels, aluminum sheets, stainless steel, acrylic, or polycarbonate panels

Surface Finish:
Outdoor powder coating, spray painting, UV printing, vinyl graphics, or electroplated finishes

Light Source:
High-brightness LED modules with IP65/IP67 waterproof options

Fuel Price Display:
Interchangeable number panels, LED digital price modules, or remote-controlled electronic price displays

Power Supply:
DC12V/24V low-voltage system with overcurrent, overload, and short-circuit protection

The combination of a reinforced structure, durable exterior materials, and high-efficiency illumination makes each gas station sign suitable for continuous outdoor operation.

2. Size & Structural Specifications

Overall Height:
Custom-made according to the installation location, visibility requirements, and local regulations

Sign Width:
Customized to match the number of branding panels, fuel price rows, and service information sections

Cabinet Depth:
Typically 150–400mm, depending on the overall dimensions and internal structure

Panel Thickness:

• Aluminum sheet: 1.0–3.0mm
• Aluminum composite panel: 3–4mm
• Acrylic or polycarbonate face: 3–10mm

Internal Framework:
Welded galvanized steel or aluminum structure with optional reinforced base plates and anchor bolts

Installation Method:
Concrete foundation installation using anchor bolts, embedded steel components, or customized mounting systems

Large-scale pylon signage can be manufactured in modular sections to simplify transportation, on-site assembly, installation, and future maintenance.

3. Lighting & Display Features

Illumination Options:

• Internal LED illumination
• Front-lit branding panels
• Backlit logo panels
• Digital LED fuel price displays
• Non-illuminated reflective graphics

Lighting Color:
White, warm white, red, green, blue, or customized LED colors

Fuel Price Control:
Supports remote control, wired control, wireless control, or mobile APP operation, depending on the selected system

Display Visibility:
High-brightness LED price modules provide clear visibility during both daytime and nighttime operation

Brightness Adjustment:
Optional automatic or manual brightness control for different lighting conditions

These display options allow the pylon sign to clearly present the gas station logo, fuel grades, current prices, convenience-store information, and other services.

4. Environmental Performance & Reliability

Working Voltage:
DC12V/24V with AC110–240V input

Working Temperature:
-20°C to +60°C

Weather Resistance:
Designed to withstand sunlight, rain, wind, dust, and changing outdoor temperatures

IP Rating:

• IP54 for protected installations
• IP65/IP67 waterproof electrical components for outdoor applications

LED Lifespan:
Up to 50,000 hours under normal operating conditions

Optional Compliance:
CE, RoHS-compliant electrical components are available according to project and market requirements

Every outdoor gas station sign is manufactured with consideration for structural strength, waterproofing, heat dissipation, electrical safety, and convenient maintenance.

5. Advantages & Limitations

✅ Advantages

High Roadside Visibility
The tall structure and illuminated display allow drivers to identify the gas station brand from a distance.

Fully Customizable Design
Dimensions, colors, logos, panel layouts, lighting effects can be customized.

Strong Outdoor Durability
Weather-resistant materials and reinforced internal structures provide reliable performance in demanding outdoor environments.

Modular Construction
Individual panels and electrical components can be accessed and replaced conveniently during maintenance.

❌ Limitations

• Large pylon signage requires a suitable concrete foundation and professional installation.
• Final dimensions and structural specifications may need to comply with local building and signage regulations.
• Digital fuel price displays have a higher initial cost than interchangeable static number panels.
• Extra-large signs may require sectional production and on-site assembly.
